TP4056 Type-C Li lon Battery Charger Module

TP4056 Type-C Li lon Battery Charger Module

DISPATCHED WITHIN 1-5 days.
24 hours RETURN/EXCHANGE POLICY
Rs. 27.00
Rs. 39.00 Rs. 27.00
Sale Sold out
Shipping calculated at checkout.

SKU: 31095
Tags: 18650 Charger Module , 1A Battery Charging Module , 3.7V Battery Charger , Arduino Power Module , Battery Management Module , Battery Protection Circuit , DIY Electronics , DW01A Protection , Embedded Systems , ESP32 Power Supply , FS8205A , Li-Ion Battery Charger , Lithium Battery Charging Board , Lithium Charger PCB , Maker Project , Portable Power Projects , Rechargeable Battery Module , TP4056 , TP4056 Protection Module , TP4056 Type-C , TP4056 USB C , USB C Charging Board , USB Type-C Charger Board
View full details

Specification: The TP4056 1A Li-Ion Battery Charging Module with a USB Type-C interface is a compact, constant-current/constant-voltage linear charger designed for single-cell 3.7V lithium-ion or lithium-polymer batteries. In a laboratory setting, it serves as a reliable, low-cost component for prototyping portable electronic devices, powering sensor nodes, or integrating rechargeable power management into custom experimental hardware.

Technical Specifications:
* Input Voltage: 4.5V – 5.5V DC
* Charging Method: Linear charging (CC/CV)
* Charging Current: 1A (adjustable via onboard resistor)
* Full Charge Voltage: 4.2V ± 1.5%
* Charging Status Indicators: Red LED (charging), Blue/Green LED (fully charged)
* Charging Accuracy: 1.5%
* Input Interface: USB Type-C
* Operating Temperature: -10°C to +85°C
* Protection: Integrated battery over-discharge/over-current protection (on protected versions)
Dimension: 3*1.5cm
Weight: 33mg

Weight

0.025 kg

Dimensions 5 × 5 × 5 cm
