RELAY MODULE 5V 1CH

Specification: The 5V 1-channel relay module is an electromechanical switching device used to interface low-voltage microcontrollers like Arduino or Raspberry Pi with high-power laboratory equipment. It serves as an essential component for automated experiments, allowing researchers to safely control AC mains devices or high-current DC loads through simple digital signals.

Technical Specifications:
* Input Voltage: 5V DC
* Channel count: 1
* Maximum load: 10A/250VAC or 10A/30VDC
* Trigger signal: TTL logic (active low or high depending on module version)
* Isolation: Integrated optocoupler for circuit protection
* Connection: Screw terminal blocks for high-voltage output
* Indicator: Built-in LED status indicator
* Control interface: Standard 3-pin headers (VCC, GND, Signal)

(The dimensions and weight mentioned in the additional information section are of the product with box/packaging.)
