RC Phase Shift Oscillator Trainer

Specification:

Product Name: RC Phase Shift Oscillator Trainer
Application: Study and demonstration of RC phase-shift oscillator using IC 741 op-amp
Op-Amp IC: IC 741
Power Supply: 230V AC, 50 Hz
DC Supply: Regulated ±15V DC
Oscillator Network: Three-stage RC phase-shift network
Resistors: 1KΩ resistors
Capacitors: 0.01 µF capacitors
Feedback Resistance: RF / Variable resistor
Variable Resistor: 47KΩ
Output Terminal: V out provided
Op-Amp Supply Pins: +12V and −12V marked
Input / Output Terminals: Color-coded banana terminals
Construction: Sturdy laboratory trainer panel with protective blue casing
Power Indicator/Control: ON/OFF power switch
Ground Terminal: Common GND terminals provided
Educational Use: B.Sc./Diploma/Engineering Electronics and Physics laboratory experiments
Experiment: Generation and study of sinusoidal oscillations using RC phase-shift network
Aim: To Study RC Shift Amplifier using Operational Amplifier (LM741)

• Dimensions: 27.5 X20.3 X8cm.
• Weight:1.020kg
• Packing: Card Board Box
• HSN CODE: 8541
• Box Dimensions:29 x 23.2 x13cm
• Weight: 1.260 kg
• GST: General Standard 18%
• CATAGORIES: ELECTRONIC APPARATUS
• BRAND: OM LABS
